| Specification | ||
Range |
: |
0-14 pH |
Sensor Output |
: |
mV (± 59.4 mV/pH change at 25°C) |
Body |
: |
Glass |
Type |
: |
Combination |
Junction |
: |
Four Ceramic Junction |
Pressure |
: |
6 Bar |
Temperature |
: |
0 ~100°C |
Shaft Length |
: |
120 mm |
Shaft Diameter |
: |
12 mm |
Membrane Resistance |
: |
200 to 500 MΩ |
Temp. Compensation |
: |
Pt 100 (Optional) |
Process Connection |
: |
PG 13.5 |
Cable |
: |
Standard Integral 5 Meters with BNC (Optional Leads) |
Cable Length |
: |
10, 15, 20, 25 Meters |
