MICROSET CONTROLS

    FEATURES
  • Microprocessor based
  • Bright LED display
  • Isolated 4 -20 mA Output Isolated
  • Two Programmable Relays
  • Communication Output - RS 484 Modbus RTU - Optional
  • Built in Memory Logging - Optional
  • Password Protection

SPECIFICATION
Display
:
4 Digit LED
Input
:
From DO2 Sensor
Range
:
0 to 20.00 ppm
Resolution
:
0.01 ppm
Accuracy
:
± 1% Full Scale
Calibration
:
2 Points – Soft Key
Set point
:
02 Nos.
Control Output
:
02 Nos. Potential free 230 VAC / 5A
Retransmission Output
:
4 to 20 mA Isolated
Communication Output
:
RS 485 Modbus RTU - Optional
Data logging
:
Built in - Optional
Temp. Compensation
:
Auto / Manual – Pt 100
Pressure Compensation
:
Manual Programmable
Operating Temp.
:
0 to 50°C
Mounting
:
Panel Mounted
Dimensions
:
96 x 96 x 85 mm
